As your microservices architecture grows, one problem hits hard and fast:

"How the heck do I trace what went wrong across services?"

If you've ever asked yourself:

• ❌ Why did a specific API call fail?
• ❌ What exactly was the incoming request and outgoing response?
• ❌ How long did that request take?
• ❌ How many 5xx errors happened today on the Order Service?

Then... this post is for you.

Let’s fix this with a custom ASP.NET Core middleware that does request-response logging, pushes structured logs directly into Elasticsearch, and lets you search/debug them in Kibana—all in near real-time 🚀.

🎯 Real-World Problem: Distributed Logging Across Microservices

Picture this setup:

• 🧑‍💻 User Service
• 📦 Order Service
• 💳 Payment Service
• 📦 Inventory Service

Each of them handling thousands of API calls per day.

Now imagine trying to debug an issue where a single request flows through 3 services and fails somewhere in the middle.

You’d want:

✅ A single place to search all logs
✅ Ability to filter by endpoint, status code, date, or correlation ID
✅ Dashboards showing error trends and response times
✅ The ability to quickly debug production issues

💡 Why Middleware-Level Logging?

Why not just sprinkle logs inside Controllers?

Here’s why middleware-based logging wins:

• ✅ Captures every request and response
• ✅ Runs automatically for all endpoints
• ✅ No clutter in your Controller logic
• ✅ Uniform structure for logs
• ✅ Captures performance metrics, headers, bodies, and errors

⚙️ Architecture Overview

Here’s what the flow will look like:

Client ➡️ ASP.NET Core Middleware ➡️ Service Logic ➡️ Middleware (on Response) ➡️ Elasticsearch ➡️ Kibana

We’re keeping things lightweight:
✅ Using Elasticsearch Low-Level Client
✅ Skipping Logstash for simplicity

🛠️ Step-by-Step Implementation

Step 1: Spin Up a New ASP.NET Core API Project

dotnet new webapi -n ApiLoggingWithElasticsearch
cd ApiLoggingWithElasticsearch

Step 2: Install Required NuGet Packages

dotnet add package Elasticsearch.Net
dotnet add package Newtonsoft.Json

These will help serialize our logs and push them to Elasticsearch.

Step 3: Build the Custom Logging Middleware

This middleware will:

✅ Read incoming request body
✅ Capture outgoing response body
✅ Measure execution time
✅ Push a structured log to Elasticsearch

using System.Diagnostics;
using System.IO;
using System.Text;
using System.Threading.Tasks;
using Microsoft.AspNetCore.Http;
using Newtonsoft.Json;

public class RequestResponseLoggingMiddleware
{
    private readonly RequestDelegate _next;
    private readonly ElasticsearchService _elasticService;

    public RequestResponseLoggingMiddleware(RequestDelegate next, ElasticsearchService elasticService)
    {
        _next = next;
        _elasticService = elasticService;
    }

    public async Task Invoke(HttpContext context)
    {
        var stopwatch = Stopwatch.StartNew();

        // Capture Request Body
        var requestBody = await ReadRequestBody(context.Request);

        // Swap response body stream
        var originalBodyStream = context.Response.Body;
        using var responseBody = new MemoryStream();
        context.Response.Body = responseBody;

        await _next(context); // Proceed with the pipeline

        stopwatch.Stop();

        // Capture Response Body
        var responseBodyText = await ReadResponseBody(context.Response);

        // Prepare Log Object
        var log = new
        {
            Timestamp = DateTime.UtcNow,
            Path = context.Request.Path,
            Method = context.Request.Method,
            RequestHeaders = context.Request.Headers,
            RequestBody = requestBody,
            StatusCode = context.Response.StatusCode,
            ResponseBody = responseBodyText,
            DurationMs = stopwatch.ElapsedMilliseconds
        };

        // Push to Elasticsearch
        await _elasticService.LogToElasticsearchAsync(log);

        // Copy response back for the client
        await responseBody.CopyToAsync(originalBodyStream);
    }

    private async Task<string> ReadRequestBody(HttpRequest request)
    {
        request.EnableBuffering();
        request.Body.Position = 0;
        using var reader = new StreamReader(request.Body, Encoding.UTF8, leaveOpen: true);
        var body = await reader.ReadToEndAsync();
        request.Body.Position = 0;
        return body;
    }

    private async Task<string> ReadResponseBody(HttpResponse response)
    {
        response.Body.Seek(0, SeekOrigin.Begin);
        string text = await new StreamReader(response.Body).ReadToEndAsync();
        response.Body.Seek(0, SeekOrigin.Begin);
        return text;
    }
}

Step 4: Create a Simple Elasticsearch Service

This service connects directly to your local Elasticsearch instance (e.g., http://localhost:9200).

using System;
using System.Threading.Tasks;
using Elasticsearch.Net;
using Newtonsoft.Json;

public class ElasticsearchService
{
    private readonly ElasticLowLevelClient _client;
    private const string IndexName = "api-logs";

    public ElasticsearchService(string elasticsearchUrl)
    {
        var settings = new ConnectionConfiguration(new Uri(elasticsearchUrl));
        _client = new ElasticLowLevelClient(settings);
    }

    public async Task LogToElasticsearchAsync(object logEntry)
    {
        var json = JsonConvert.SerializeObject(logEntry);
        var response = await _client.IndexAsync<StringResponse>(IndexName, PostData.String(json));
        Console.WriteLine($"Elasticsearch Log Status: {response.HttpStatusCode}");
    }
}

Step 5: Register Middleware in ASP.NET Core

Modify your Program.cs (for .NET 6+ style):

var builder = WebApplication.CreateBuilder(args);

// Register ElasticsearchService
builder.Services.AddSingleton(new ElasticsearchService("http://localhost:9200"));

var app = builder.Build();

// Plug in our middleware
app.UseMiddleware<RequestResponseLoggingMiddleware>();

app.MapControllers();
app.Run();

Step 6: Run and Test 🚀

dotnet run

Then hit an endpoint like:

curl http://localhost:5000/weatherforecast

Step 7: View Your Logs in Kibana 📊

1. Open Kibana
2. Go to Discover
3. Select the index: api-logs
4. Start filtering/searching logs by:

• Path
• StatusCode
• DurationMs
• Timestamp
• RequestBody
• ResponseBody

You can even build custom dashboards showing error rates, average response times, etc.

✅ Benefits of This Approach

✅ No external logging frameworks needed (No Serilog, NLog, etc.)
✅ Works at middleware level—no code changes needed in Controllers
✅ Searchable, structured JSON logs
✅ Easy to extend with trace IDs, exception handling, etc.
✅ Real-time visibility using Kibana

💬 Final Thoughts

This setup gives you a production-ready, low-maintenance, and extensible foundation for centralized API logging across all your microservices.

If you want, you can find the full source code on GitHub.
